Abyzz AFC400

Abyzz AFC400IPU – Flow pump

SPECIAL ORDER ITEM ONLY

The innovative Abyzz Flow Cannon AFC400 with its high-end design including a titanium rotor unit, titanium mounting frame and carbon fibre parts next to durable plastics consists of the pump itself and a powerful and programmable driver. Containing a very energy efficient motor and providing the exact adjustment for your application, it offers a very energy-saving solution. The integrated bearing flushing provides optimum protection against calcification and, in conjunction with the silicon carbide bearings and special hard metal shaft, ensures low-maintenance operation. All metal parts are made out of titanium grade 2 and other parts are made out of high quality PA, PVC and carbon fibre. This composition ensures a long lifetime, thus granting highest sustainability and lowest carbon footprint. Several mounting options are offered to suit any needs. Due to many available mounting points, even a customer specific mounting can be done very easily. The special three-bladed prop and a well designed hydraulic lets the pump operate with almost no noise or vibration. An additional coat flow ring provides low output speed and a softened laminar flow. Easy programming (as in any Abyzz pump) and the possibility to link to external controllers offers a wide field of application. The materials used are designed to have a long lifetime and meet the highest requirements and quality standards. This product is developed and manufactured in Germany by venotec.

Special features

• Variable speed range (0 – 100%)
• Programmable control (eg wave and random mode)
• Extensive protection against e.g. dry running,
• overtemperature and overcurrent)
• Smooth start
• Bus-capable interface for peripherals
• Lockable plug contacts
• Low noise operation
• Wide range of mounting options
• Rock-stable mounting available (not included)

Applications

• Freshwater and seawater aquaristics
• Ponds
• Creeks
• Large scale aquariums
• Shark tanks

Technical data

• Mounting only submersed, minimum submersion depth 0,6m
• Flow (nominal): 165.000 l / h (720 gpm)
• Flow (max.): 220.000 l / h (960 gpm)
• Discharge speed (max.): 3,3 m / s (10 ft / s)
• Power consumption: 4 … 400W
• Operating voltage: 200… 240V ~ oder 90… 120V ~
• Operating frequency: 50… 60Hz (Netz)
• Ambient temperature: + 2 ° C… + 40 ° C (Fahrer)
• Immersion depth (max.): 8m
• Cable length (pump): 10m

Delivery

• Abyzz AFC400IPU and driver AFC400IPU (splash-water protected)
• Power cable and connection cable
